Service
FOUNDRY
Our in-house foundry specializes in producing Grey Iron, Ductile Iron, and Austempered Ductile Iron (ADI) castings. With over 500 MT/month capacity, we control every variable: sand quality, core strength, melt chemistry, and pouring temperature. We use green sand jolt squeeze molding and CO₂ core processes tailored to your part's geometry and critical zones. Our casting process is designed to ensure superior surface finish, high dimensional stability, and on-time delivery (OTD) even with low-MOQ batch requirements.
We support component weights from 1 kg up to 100 kg, with a maximum mold box size of 700 × 800 mm (L × B). The foundry is equipped with two 500 kg induction furnaces to ensure consistent melting and alloying control. We also operate a dedicated shell core making machine for high-precision internal cavities and smooth surface finish in core areas.
We also have a network of approved vendors for:
High-weight components exceeding 100 kg, with partner facilities capable of casting single pieces up to 20 metric tons
Hand molding of large and low-volume components
Non-ferrous castings in bronze and brass (job work under our inspection)
Capabilities
From Vision to Reality Our Design Services
Cover Every Corner of Your Home
CAST IRON GRADES OFFERED:
| Type | Grade | Standard |
|---|---|---|
| Ductile Iron (SG Iron) | SGI 400/18 | ISO 1083 / ASTM A536 |
| SGI 450/12 | ISO 1083 / ASTM A536 | |
| SGI 500/7 | ISO 1083 / ASTM A536 | |
| SGI 600/3 | ISO 1083 / ASTM A536 | |
| SGI 700/2 | ISO 1083 / ASTM A536 | |
| Austempered Ductile Iron (ADI) | Grade 1 – 900/9 | ASTM A897 |
| Grade 2 – 1050/7 | ASTM A897 | |
| Grade 3 – 1200/6 | ASTM A897 | |
| Grade 4 – 1400/4 | ASTM A897 | |
| Grade 5 – 1600/2 | ASTM A897 | |
| Gray Cast Iron | FG 200 | IS 210 / ASTM A48 |
| FG 260 | IS 210 / ASTM A48 | |
| FG 300 | IS 210 / ASTM A48 | |
Ideal For : Low to heavy weight components in the range of 1 kg to 100 kg, including cores and structural shapes requiring surface finish and low-quantity flexibility
